| Generator | Rating frequency(Hz) | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Rating Voltage(V) | 110/120/220/230/240 | ||||||||||
| Rating power(KVA) | 2 | 2.3 | 2.3 | 2.5 | 2.8 | 3.2 | 5 | 5.5 | 6 | 6.5 | |
| The Max.power(KVA) | 2.2 | 2.5 | 2.5 | 2.7 | 3 | 3.5 | 5.5 | 6.0 | 6.5 | 7.0 | |
| Power factor(cos) | 1 | ||||||||||
| Engine | Type | 168F | 168F-1 | 170F | 188F | 190F | |||||
| Category | Single crock,Force air-cooled four-stroke,top-intalled gasoline engine | ||||||||||
| Exclusion of cylinder(cm3) | 163 | 196 | 220 | 389 | 420 | ||||||
| The Max.output power(KW/rpm) | 4.1/3600(5.5HP) | 4.8/3600(6.5HP) | 5.1/3600(7.0HP) | 9.6/3600(13HP) | 11/3600(15HP) | ||||||
| Ignition system | Transistorized magneto | ||||||||||
| Start system | Recoil/E-start | ||||||||||
| Capacity of fuel tank(L) | 15 | 15 | 15 | 25 | 25 | ||||||
| Consumption of fuel(L/h) | 1.13 | 1.32 | 1.9 | 2.7 | 2.95 | ||||||
| Consecutive Working(h) | 13 | 11 | 10 | 10 | 9 | ||||||
| Noise(at7m)(dB) | 65 | 65 | 69 | 72 | 74 | ||||||
| Capacity of engine oil | 0.6 | 1.1 | |||||||||
| Dimension | Set dimension(mm3) | 605×435×445 | 605×435×445 | 605×435×445 | 670*510*510 | 670×510×510 | |||||
| Net weight(kg) | 39 | 40 | 42 | 78 | 80 | ||||||
| 20GP/40HQ | 240/580 | 240/580 | 240/580 | 144/288 | 144/288 | ||||||
| Standard Equipment | Large capacity fuel tank,large capacity muffler,fuel gauge,voltmeter,AVR,oil alert,Ac circuit breaker | ||||||||||
| Purchasing | Four-wheel dolly kit | Yes | |||||||||
|
|
